Which loading volume garbage compactor truck can provide you best environmental protection service

Brief introduction of garbage compactor truck:

The Garbage Compactor Truck is usually called compactor garbage truck, refuse compression truck, trash compressor truck,garbage collection truck, compressed refuse truck,etc.

Our garbage compactor truck for sale is constructed with 12# low alloy steel and 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the DONGFENG truck beam.The body floor is fully sealed.All the sewage can godirectly into the sewage tank,so as not to corrode the body and chassis.Moreover,it can also prevent the sewage leakage while the truck is driving onthe road and avoid the secondary pollution.

The garbage compactor truck usually compacts the waste using a hydraulically powered mechanism that employs amoving plate or shovel to scoop the waste out from the loading hopper andcompress it against a moving wall. In most compactor designs, the plate has apointed edge (hence giving it the industry standard name packer blade) which isdesigned to apply point pressure to the waste to break down bulky items in thehopper before being drawn into the main body of the truck.

There are three kinds of mechanism options available to the customer, barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process, which isvery safe and reliable.

As a professional special vehicle manufacturerin China, with advanced international certificate, the waste garbage compactor trucks we produce is from 3m³ to 22m³.

Items	Descriptions	Specifications and Types
General	Truck Name	Garbage Compactor truck
	Drive Type	4*2, left hand drive
	Loading Capacity	10-14 m³
	Gross Vehicle Weight(kg)	16000
	Curb Weight (kg)	9805
	Overall Dimensions LWH(mm)	8470×2490×3250
Engine	Engine Model	ISDe210 40
	Engine Brand	Cummins
	Fuel Type	Diesel
	Power	140kw/190HP
	Emission Standard	Euro 3
	Displacement(ml)	6700
	Engine Type	6 cylinders in line,water cooling, turbo-charged diesel engine,inter-cooling
Chassis	Chassis Brand	DongFeng
	Front/Rear Axle Load(KG)	6000/10000
	Tire No.	6+1
	Tire Specification	9.00-20 Nylon tire or 9.00R20 steel tire
	Wheelbase (mm)	4500
	Axle No.	2
	Gear Box	6 speed forward with 1 reverse, manual
	Brake	Air break
	Radiator	Suitable for tropical climate
	Front/rear suspension(mm)	1430/2540
	Leaf Spring No.	8/10+8
Equipment: 1. Equipped with completely sealed dustbin, hydraulic system, operation system. 2. Equipped with rear turnover mechanism,can hook dustbin or loading garbage by itself. 3.Equipped screeds and push shovel, compress by itself.High compression ratio.The sewage will flow to sewage tank automatically, avoid second pollution. Good sealed performance, easily operation, and high safety.
